Understanding Azure Custom Routing Architecture – Part 5

This architecture outlines the step-by-step process for configuring route tables in the Azure portal.

Steps:

  1. Access Azure Portal:
  • Open the Azure Portal and navigate to the Dashboard.
  1. Navigate to Services:
  • Select “All services” from the dashboard.
  1. Networking Section:
  • Navigate to the “Networking” section.
  1. Route Tables:
  • Select “Route tables” within the Networking section.
  1. Create Route Table:
  • Click the “Create” button to begin the creation of a new route table.
  1. Fill in Details:
  • Enter the required details for the new route table (e.g., name, subscription, resource group, region).
  1. Review and Create:
  • Review the details entered and click “Create” to finalize the route table.
  1. Configure Routes:
  • Once the route table is created, navigate to the “Routes” section to configure specific routes.
  1. Add Route:
  • Click “Add route” to add a new route to the table.
  1. Specify Route Settings:
  • Enter the route settings, including the address prefix and next hop type (e.g., virtual network gateway, internet, virtual appliance).
  1. Save Route:
  • Save the route settings to apply the new route.
  1. Verify Routes:
  • Verify the route settings to ensure correctness.
  1. Complete Setup:
  • Finish the setup and ensure all configurations are correct and applied.



Summary:

This architecture provides a comprehensive guide for setting up and configuring route tables in the Azure portal, ensuring a systematic approach to managing network routing within the Azure environment. Each step is crucial for the correct implementation and verification of routing settings to maintain efficient network traffic management.
